T2 THERMOSTAT
Intelligent temperature control |
|
| Width | 84 mm |
| Color | White |
| Height | 84 mm |
| Depth | 40 mm |
| RAL number | 9010 |
| With display | Yes |
| Type of control | On/Off |
| With thermal feedback | Yes |
| Type of power supply | 230 V |
| Measuring range | 5 to 40 °C |
| Operation | Button |
| Remote control possible | No |
| Adaptive (self-learning) | Yes |
| Type of clock | Weekly timer |
| Protection class (IP) | IP21 |
| Sensor type | Resistance sensor |
| Standby power consumption (solar standby) | 0.4 W |
| Suitable for district heating control | No |
|---|---|
| Suitable for underfloor heating control | Yes |
| With presence detection | No |
| Ventilation | No |
| Number of ventilation outputs | 0 |
| Max contact voltage | 230 V |
| With receiver | No |
| Control characteristic | PI |
| Weather-dependent control system | No |
| With hot water circuit | No |
| Number of heating outputs | 1 |
| Clock model | Digital |
| Number of cooling outputs | 0 |
| Readable temperature | Yes |
| Number of control programs | 2 |
| Heating | Yes |
| Cooling | No |
| Max contact load | 13 A |
| Differential value | 0.2 K |
| Contact type | Normally open contact |
| Adjustable differential | No |
| External sensor | Yes |
